Basic Info.
Model NO.
stainless steel wire mesh
Hole Shape
Round
Application
Filter, Construction Wire Mesh, Protecting Mesh, Screen, Decorative Mesh, Fence Mesh, Barbecue Wire Mesh, Window Curtain, Cages
Type
Stainless Steel Plain Wire Mesh
Material Type
Stainless Steel Wire
Weave Technique
Twill Weave /Plain Weave/Dutch Weave
Wire Mesh Width
0.2m-2m
Technique
Woven
Nickels
10%
Certification
ISO9001
Feature
Corrosion Resistance
Length
Each Roll of Stainless Steel Mesh Is 10 Feet Long
Surface Treatment
Untreated
Mesh
3-2600 Mesh
Transport Package
Wooden Box
Specification
stainless steel
Trademark
Joysun
Origin
China
HS Code
73144900
Production Capacity
7000 Volumes Per Year
Packaging & Delivery
Package Size
100.00cm * 20.00cm * 20.00cm
Package Gross Weight
5.000kg
Product Description
Preparation Method
1,Plain Weave: The most basic weaving pattern where warp and weft threads cross each other to form a flat surface.
2,Twill Weave: A weaving pattern in which weft threads pass over or under multiple warp threads, creating a diagonal line.
3,Plain Dutch Weave: Similar to plain weave but with different wire diameters, resulting in smaller mesh openings.
4,Twill Dutch Weave: Similar to twill weave but with different wire diameters, creating a denser mesh structure.
5,Reverse Dutch Weave: Differs from standard Dutch weave with thicker warp wires and fewer weft wires for higher strength and larger particle filtration capacity.
The Use Of Stainless Steel Mesh
T-304 stainless steel is the most widely available of all stainless steels in the wire mesh industry. Aside from the countless combinations of mesh opening sizes and diameter wire available both from stock and through manufacturing, T-304 SS exhibits many benefits and is largely considered the standard of the industry. T-304 SS has excellent corrosion resistance in a wide range of environments and is used in a wide range of applications.Some of the more popular applications and industries that use T-304 and T-316 stainless steel are listed below:
Raw Material Introduction
T-304 stainless steel is known for its superior heat resistance, corrosion resistance, manufacturing versatility, and cost-effectiveness. It can withstand high temperatures and has good corrosion resistance, making it ideal for a variety of applications. It is easy to form and precisely cut for an efficient manufacturing process. In the annealed condition, T-304 stainless steel is non-magnetic, increasing its usability. It is commonly used in the wire mesh industry and has two forms of weaving and welding, which can flexibly meet different requirements.
Specifications
| Mesh Count per Linear Inch | Wire Diameter (inch) | Wire Diameter (mm) | Opening Width (inch) | Opening Width (mm) | Area (%) |
| 30 x 30 | 0.012 | 0.3 | 0.021 | 0.53 | 40.8 |
| 50 x 50 | 0.009 | 0.23 | 0.011 | 0.28 | 30.3 |
| 80 x 80 | 0.0055 | 0.14 | 0.007 | 0.17 | 31.4 |
| 100 x 100 | 0.0045 | 0.11 | 0.006 | 0.15 | 30.3 |
| 120 x 120 | 0.0037 | 0.09 | 0.005 | 0.12 | 30.7 |
| 150 x 150 | 0.0026 | 0.066 | 0.0041 | 0.1 | 37.4 |
| 180 x 180 | 0.002 | 0.05 | 0.0035 | 0.09 | 41.1 |
| 200 x 200 | 0.0016 | 0.04 | 0.0035 | 0.089 | 46 |
